| Size | 600x600x630mm |
| weight | 130±5KG |
| power supply | signle phase, AC220V,50HZ |
| Max power | 2.8KW |
| drive motor | servo motor |
| drive precision | ±0.005mm(XYZ), ±0.001rad(A) |
| spindle power | 1.8kw |
| spindle speed | 5000-60000rpm |
| max feeding rate | 6000mm/min(XYZ) |
| number of axis | 4 |
| number of tools | 6 |
| tool diameter | 6mm |
| tool length | 50±1mm |
| travel | 110mm(X),135mm(Y),75mm(Z) |
| tilt angle | 360°（A） |
